CM/2464-1061/2A-SB LF

Product Description

For Quotation, please click the Contact Us button below.

(1coil/100m≒328ft) Basically 100m MOQ,

Cutting under 100m or Made to order should be confirm with us.

Application

• Cable for RS232（Only multi pair cables)
• It is possible to use it as a communication tray cable.
• The substitutions for UL13 CL3 ,CL3X, shall be permittShielded ded Electric equipment cable with UL and cUL at 300V,80℃.(Category : DUZX,DUZX7,AVLV2,AVLV8)
• Obtaining UL Listed CM, this cable compliants to NFPA70,79.

Feature

• Semi-rigid PVC used insulation.
• Oil, heat resistant and Flexible PVC sheath
  material is used.

• Flame resisting:UL VW-1,cUL FT1.

• It passes Vertical-Tray Flame Test of UL.

Allowable ampacity

・The allowable ampacity of this catalog is a value at one in the air construction and the ambient temperature 30℃.

・Allowable ampacity is calculated based on JCS0168.
・Please multiply the following correction coefficient by the ambient temperature.

●  Adjustment factors（at ambient temperature）

● Standard sales length

100m. (Sales by short length is available for large sizes. Please contact us which sizes are available. ）
