CM/2464-1007/2A-SB LF

Available
Login to View Price

For Quotation, please click the Contact Us button below.

(1coil/100m≒328ft) Basically 100m MOQ,

Cutting under 100m or Made to order should be confirm with us.



Application

  • Cable for RS232(Only multi pair cables)
  • It is possible to use it as a communication tray cable.
  • The substitutions for UL13 CL3 ,CL3X, shall be permitted.
  • Shielded Electric equipment cable with UL and cUL at 300V,80℃.
  • (Category :DUZX,DUZX7,AVLV2,AVLV8)
  • Obtaining UL Listed CM, this cable compliants to NFPA70,79.

Feature

  • Heat resistant PVC used for insulation.
  • Oil, heat resistant and Flexible PVC sheath
    material is used.
  • Flame resisting :UL VW-1,cUL FT1.
  • It passes Vertical-Tray Flame Test of UL.







Allowable ampacity

・The allowable ampacity of this catalog is a value at one in the air construction and the ambient temperature 30℃.

・Allowable ampacity is calculated based on JCS0168.

・Allowable ampacity is calculated excluding grounding conductor.
・Please multiply the following correction coefficient by the ambient temperature.

(Note) Please refer to P.276 when you use this cable according to NFPA70.

●  Adjustment factors(at ambient temperature)

● Standard sales length

100m. (Sales by short length is available for large sizes. Please contact us which sizes are available. )










  • Certification:
    CM/2464-1007/2A-SB LF
  • Category:
    Global Cables,Robot Cables
  • Manufacturer:
    TAIYO
  • Insulator:
    Heat resistant PVC
  • Cable Carrier Resistant
  • Flame Retardant
  • Flexible Robot Cable
  • Heat Resistant
  • Oil Resistant
  • Shielded
  • Torsion Resistant
SIZE(AWG)
Number of cores
Product Description

For Quotation, please click the Contact Us button below.

(1coil/100m≒328ft) Basically 100m MOQ,

Cutting under 100m or Made to order should be confirm with us.



Application

  • Cable for RS232(Only multi pair cables)
  • It is possible to use it as a communication tray cable.
  • The substitutions for UL13 CL3 ,CL3X, shall be permitted.
  • Shielded Electric equipment cable with UL and cUL at 300V,80℃.
  • (Category :DUZX,DUZX7,AVLV2,AVLV8)
  • Obtaining UL Listed CM, this cable compliants to NFPA70,79.

Feature

  • Heat resistant PVC used for insulation.
  • Oil, heat resistant and Flexible PVC sheath
    material is used.
  • Flame resisting :UL VW-1,cUL FT1.
  • It passes Vertical-Tray Flame Test of UL.







Allowable ampacity

・The allowable ampacity of this catalog is a value at one in the air construction and the ambient temperature 30℃.

・Allowable ampacity is calculated based on JCS0168.

・Allowable ampacity is calculated excluding grounding conductor.
・Please multiply the following correction coefficient by the ambient temperature.

(Note) Please refer to P.276 when you use this cable according to NFPA70.

●  Adjustment factors(at ambient temperature)

● Standard sales length

100m. (Sales by short length is available for large sizes. Please contact us which sizes are available. )
