EL8100 Series

The EL8100 Series provides media conversion between 10/100/1000BASE-TX and 1000BASE-SX/LX/BX Fiber.

Built specifically for mission critical applications in harsh environments, the EL8100's hardened design features high shock & vibration resistance, electrical noise immunity, wide operating temperature range from -40 to 75°C (-40 to 167°F), and aluminum housing.

With two power inputs, link down alarming, Link-Fault-Pass-Through and a wide range of fiber connectivity options, the EL8100 is the ideal media converter for environments where connectivity is crucial.


• Full Gigabit bandwidth and Jumbo frames
◦10/100/1000BASE-TX and 1000BASE-SX/LX/BX Ethernet transmission conversion
◦1000Mbps Full duplex and full wire-speed forwarding rate
◦ Jumbo frames up to 10K bytes to increase throughput and transmission efficiency

• Port Failure Alarm
◦ Relay alarm configured by DIP switch to notify users when power fails or link is down

• Hardened Grade

◦ Supports -40 to 75°C (-40 to 167°F) operating temperature
◦ Redundant power inputs on terminal block connector
◦ Supports DIN-Rail mounting

• Link-Fault-Pass-Through (LFPT)
◦ Provides constant monitoring of the links connected to the media converters
◦ If a copper or a fiber link fails, the media converter will pass the fail state on throughout the link, disabling the fiber link and the copper link on the opposite end
